Andrew OM24SNG-RC - Manual (Page 22)

Antenna Electrical Operating Frequency Band
Ku-Band Receive Ku-Band Transmit
10.95-12.75 GHz 14.0-14.5 GHz
Gain at circular waveguide flange of feed
2-Port
Rx Frequency Rx Gain Tx Frequency Tx Gain
11.950 GHz 47.7 14.25 GHz 49.2
4-Port
Rx Frequency Rx Gain Tx Frequency Tx Gain
11.950 GHz 47.4 14.25 GHz 48.9
Polarization Linear
Polarization Discrimination, on axis >35 dB
across 1dB contour 27 dB
Beamwidth, at Midband Ku-Band
3 dB Receive (Transmit) 0.72° (0.61°)
15 dB Receive (Transmit) 1.42° (1.33°)
Antenna Noise Temperature under clear sky conditions, at 68° F
(20° C), at the circular waveguide flange of the feed.
Elevation Ku-Band (2-Port) Ku-Band (4-Port)
10° 44° 72°
30° 33° 61°
Antenna VSWR, Transmit and Receive <1.3:1
Radiation Pattern Performance PE’s #4471 and #4472
Tx Power Handling Capability
2-Port Network, maximum, W 2000
4-Port Network, maximum, W 600
Feed Interface Flanges, Receive/Transmit WR75
Isolation, minimum, Tx into Rx, dB 40 (2-Port) 85 (4-Port)
Power Density Data
Projected Width of Reflector 96 in
Area of Feed Horn Aperature 10.65 in 2
Focal Length 60 in
Optional Cross Axis Kit, loss, 1 dB 1XAK-LTE (1 run) 2XAK-LTE (2 runs)
All designs, specifications and availabilities of products and services
presented in this Bulletin are subject to change without notice.
22 Specifications
Specifications
