Antenna Dimensions
24 Specifications
Antenna Overall Dimensions - Top View
10’-0”
8’-3”
Elevation and
Articulation Axis
Note:
Antenna Shown
in Stowed Position
X
Y
Antenna Overall Dimensions - Side View
Azimuth
Axis 9’-11”
2’-7”
7’-4”
5”
1’-6”
2” 12”
15”
2’-0”
8 x ш .562”
ш 11.5”
ш 16.25”
11.25°
45°
Stowed
Antenna
Position
Mounting Pattern on Truck
Approximate Antenna Weight Distribution
4’-9”
4’-6”
Elevation and
Articulation
Axis
2’-2”
2”
Antenna CG 690 lbs
Reflector Only 177 lbs
1’-9” 9”
Boom Only
CG 126 lbs
(no electronics)
Mount Only
CG 387 lbs
Azimuth
Axis
1”
12”
16”
9”
