Andrew OM24SNG-RC - Manual (Page 23)

Antenna Mechanical Configuration ESA24SNG-LTE
Feed Type Prime Focus, Offset
Reflector Material Precision-Formed Aluminum
Reflector Segments 1
Mount Type El over Az, Pedestal
Material/Finish
Reflector Aluminum
Feed Brass
Positioner Aluminum
Feed Arm
Capacity 180 lbs
Area 29.5” x 36.5” x 12” High (8.3 ft 3 )
Antenna Pointing Range, Continuous
Elevation 65° (optional 90°)
Azimuth 180°, 270°, 350°
Polarization ±90°
Wind Loading, Survival
65 mph (105 km/h) in any position of operation
Wind Loading, Operational (motor drives)
45 mph (72 km/h), gusting to 65 mph (105 km/h)
Temperature, Operational -40° to 125° F (-40° to 52° C)
Rain 4 in (102 mm) per hour
Solar Radiation 360 BTU/hr/ft 2 (1135 Watts/m 2 )
Relative Humidity 100%
Atmospheric Conditions Moderate coastal/industrial
areas. Severe conditions require
additional protection.
Positioner Travel Rates, degrees per second
Elevation 0.25° to 1.0°/second
Azimuth 0.25° to 1.0°/second
Polarization 0.5° to 2.0°/second
Weight, Net 690 lbs
Electrical Requirements
Local Unit Clean/Conditioned
Voltage 190-250 Vac, 1ø, 50/60 Hz
Power 1.5 kVa, total
Remote Unit Clean/Conditioned
Voltage 100-240 Vac, 1ø, 50/60 Hz
Power 1.3 A, maximum
Maximum Branch-Circuit,
Short-Circuit and Ground-Fault Protection Device:
1ø Input 20 A inverse time breaker
23 Specifications
