Rack Power Distribution Unit — AP7610 13
Specifications
AP7610
Electrical
Input connector NEMA L21-20 plug
Output connectors Three NEMA L5-20 outlet; Three NEMA L6-20 outlet
Nominal input voltage 208 (3PH)
Acceptable input voltage 100–125/200–250 VAC
Maximum Input Current
(per phase)
16 A
Load Capacity 7200
Physical
Size (H x W x D)
3.5 Ч 17.6 Ч 6 in
(8.89 x 44.7 x 15.24 cm)
Weight 7.85 lb (3.57 kg)
Shipping dimensions
(H x W x D)
7.75 Ч21 Ч9.25 in
(19.68 x 53.34 x 23.5 cm)
Shipping weight 10.5 lb (4.77 kg)
Environmental
Elevation (above MSL):
Operating:
Storage:
0 to 10,000 ft (0 to 3000 m)
0 to 50,000 ft (0 to 15 000 m)
Temperature:
Operating:
Storage:
23 to 133° F (–5 to 45° C)
–13 to 149° F (–25 to 65° C)
Humidity:
Operating:
Storage:
5 – 95%
5 – 95% non-condensing
Compliance
Approvals cUL Listed, FCC Part 15 Class A, UL Listed, VCCI
