User Manual 30 Y1-03-0203 Rev.L
f) Long Range Interrogation
Mobile, and shore-based stations have the ability to interrogate vessels and make requests for
informat
ion over the “Long Range Interface”. The interrogated vessel can either reply in automatic,
or in manual mode. The interrogation request is displayed in both modes.
The arrival of a Long Range Interrogation Request is indicated by:
1L on the top right hand corner of the Navigation Screen. The LRI automatically arrives in the
Message Inbox LRI and can be handled from there.
Handling a Long Range Interrogation (LRI)
Default Settings for LRI Requests:
Automatic Mode:
The LRI is automatically dealt with and own vessel data is sent.
Manual Mode: The LRI needs to be manually handled.
NOTE:
The data which may be interrogated via the Long Range Interface can be configured in Menu
5: Configuration, Submenu 5: Interrogation Settings.
LAT:N 1 o 20.256'ExtSOG:34.6kn * 1L
LON:E 0 o 13.700'ExtCOG:173.0 o 07:44:49
IntGPS: 3D ExtHDT:222 o Reg6 SRM /B
001/021..ShipName....RNG.BRG..SOG..COG..
1>DOREEN-----------> N/A 120 22.2 301.5
2>FINE EAGLE------->0.00 N/A 13.1 359.9
3>SYLVAEPSILON----->0.10 23 32.1 203.2
4>ESSOTOKYO-------->0.43 99 10.0 120.3
5>OLYMPIAHIGHWAY FE>0.59 342 21.2 50.0
6>SANEI------------>0.80 272 32.1 270.1
7>KATOO------------>1.00 321 21.2 200.8
8>OLYMPIA PALACE--->1.34 277 [BASESTAT]
9>MINILOG---------->1.96 201 21.7 102.2
10>ALIBRAHIMYA----->2.66 340 22.1 30.3
11>TITANIC--------->2.75 121 N/A N/A
12>BWRTZ123-------->3.36 66 24.1 2.9>
