Description of the Application Board System
3-4
RFID Application Kit ATAK2270 User Manual
4871E–RFID–04/08
3.3.3
Antenna Interface Parts List
U1
U2270 B
SO16
U2
LM7808
TO220
3.3.3.1
Diodes
D1
BAS21
SOT23
D2
BAS21
SOT23
D3
BAS21
SOT23
D4
BAS21
SOT23
D5
BAS21
SOT23
D6
BAS21
SOT23
D7
BAS21
SOT23
DZ1
BZX84C
5.6V
SOT23
3.3.3.2
LEDs
LD1
TLMC3100 (green)
PLCC2
LD2
TLMT3100 (red)
PLCC2
LD3
TLMT3100 (red)
PLCC2
LD4
TLMA3100 (yellow)
PLCC2
3.3.3.3
Transistors
T1
BF820
SOT23
T2
BF820
SOT23
3.3.3.4
Resistors
R1
3.6 k
Ω
0805
R2
360
Ω
0805
R3
10 k
Ω
0805
R7
1 k
Ω
0805
R8
68 k
Ω
0805
R9
43 k
Ω
0805
R10
1 k
Ω
0805
R11
390 k
Ω
0805
R12
75 k
Ω
0805
R13
100 k
Ω
0805
R14
24
Ω
0805
R15
1 k
Ω
0805
R16
3.6 k
Ω
0805
R17
1.5 k
Ω
0805
R18
100
Ω
0805
R19
1 k
Ω
0805
R20
3.6 k
Ω
0805
R21
1.5 k
Ω
0805
R22
100
Ω
0805
