Brother PT-9500PC - Manual (Page 20)

19
0
Click [Close].
→The Brother PT-9500PC Properties
sheet appears again.
a
Click [OK].
→Setup is complete and the “Brother
PT-9500PC Properties” sheet will
close.
Changing the baud rate on
the PT-9500PC
The serial interface baud rate is set to 115,200
bps at the factory.
When using a personal computer that does not
support a serial port baud rate of 115,200 bps,
change the PT-9500PC baud rate to 9,600 bps.
1
Turn off the PT-9500PC.
2
With the PT-9500PC power off, press the
power button on the PT-9500PC for 5
seconds or more.
→The ERROR lamp (red) and power
button lamp (green) will flash
alternately.
3
After the lamps flash alternately, release
the power button.
→The baud rate is now set to 9,600
bps.
Power button
