10

PT-9500PC terms

This section identifies the main PT-9500PC terms.

Front view

Rear view

Note

●

If the tape compartment cover is left open, dust will collect on the print head. Always close the
cover.

Note

●

The USB ID switch is usually set to “2.” For details, refer to “Changing the USB ID mode” (→
P.20).

Tape compartment cover

Label outlet

Collection tray support

Cover release button

ERROR lamp

Power button (including lamp)

Feed/cut button

USB ID switch

USB port

AC adapter jack

Serial port
