Brother SC-2000USB - Manual (Page 29)

25
DESIGINING A STAMP (Stampcreator P-touch Editor)
Using special design frames
Selecting a frame design
1
Type in the text (refer to the section “Typing text” on page 19).
☞ NOTE: Text can be inserted before or after drawing
a frame.
2 Select the Frame tool.
3 Drag the pointer at the desired location in the layout area to draw the
frame.
4 With the Select tool, double-click inside the frame to display the Frame
Properties dialog box (see figure 19).
5 Select the desired frame settings from the “Category” drop-down list
and “Style” list, and then click the OK button.
• The selected frame design appears in the layout area (see figure 20).
☞ NOTE: To change the frame size, refer to the
section “Changing the frame size” on page 24.
Deleting a frame
1
With the Select tool, click the frame.
2 Press the Delete key on the keyboard.
figure 19
figure 20
