6
SET UP
Connecting the Interface and Power Supply Cables
After connecting the interface and power supply cables to the SC-2000USB, it can be used to create stamps from any layout
that you design in the Stampcreator P-touch Editor software or Stampcreator Express software installed on your computer.
1 Be sure both the SC-2000USB and the computer are turned off.
2 Attach the appropriate interface cable connector to the computer port.
☞ NOTE: After connecting the 9-pin connector, be sure to tighten the screws to
lock it into place.
3 Connect the other end of the interface cable to the interface jack on the back of the SC-2000USB.
4 Insert one end of the power supply cord into the power supply jack on the SC-2000USB and the other end of the cord
into an AC outlet.
System Requirements
Computer Requirements
Check that your system meets the following requirements.
• OS: Windows ® XP / Windows Vista ®*1 / Windows ® 7 *1
• Interface: USB port (USB Spec 1.1 or 2.0 protocol)
COM port (9-pin RS-232C serial port that supports 115,200 bps)
• Hard Drive: Over 70MB of available space *2
• Memory: Windows ® XP: 128MB or more *2
Windows Vista ® : 512MB or more *2
Windows ® 7: 1 GB (32-bit) or 2 GB (64-bit) or more
• Monitor: SVGA, high color or higher graphics card
• Others: CD-ROM drive, pointing device
*1 The computer should meet Microsoft ® 's recommendations for the OS installed.
*2 Required available space when installing the software with all of the options.
USB connector
8-pin connector
Back:
USB connector jack
9-pin connector
9-pin connector
USB connector
8-pin connector jack Power supply jack
Power switch
