About your printer, About your printer -2 – Brother HL-1240 User Manual
Page 10
1-2
About your printer
Fig. 1-2 Front View
Fig. 1-3 HL-1030/1240 Rear View Fig. 1-4 HL-1250 Rear View
Tray extension flap
Control panel
Front cover
Paper cassette
Manual feed slot
Manual feed paper guides
Face down output tray
Rear cover
AC power inlet
Parallel Interface connector
USB (Universal Serial Bus Interface)
connector (HL-12401250 Only)
Power switch
Parallel interface connector
AC power inlet
Power switch
Rear cover
Modular jack for lower tray unit
