FriendlyNET VPN Security Router 6
3. Expand this dialog box by clicking on the More Info >> button.
4. Complete the information in this table:
Tip: Next to the DNS Servers field, click the button to show the
Secondary DNS (if available).
5.
From the Windows Start button, choose Settings and select
Control Panel. Double-click the Network icon.
6. In the Configuration tab, highlight the TCP/IP protocol line as-
sociated with your network card adapter.
7. Click Properties to open the TCP/IP Properties dialog. Click the
IP Address tab. Select Obtain an IP address automatically.
Click OK.
8. Click OK again. Windows will begin copying files to your com-
puter. Click Yes to restart your computer with the new settings.
Repeat steps 1-3 and 5-8 to configure additional PCs on your net-
work.
Note: Keep your Windows CD handy. You may be asked to insert it
so that Windows can copy necessary files.
Windows NT/2000
1. From the Windows Start button, choose Run. In the dialog box,
type command and click OK.
2. At the command line, type the command ipconfig /all and
press Enter.
3. Fill in the table below with the data from the screen.
Item No. IP Configuration Description Your Setting
1 Host Name Host Name
2 DNS Servers Primary DNS
3 Secondary
4 Adapter Address MAC Address
5 IP Address WAN IP Address
6 Subnet Mask WAN Subnet Mask
7 Default Gateway WAN Gateway
