2. Settings regarding TOHO communications
2.1 Overview
Before communications is performed, initial settings must be made on this product. Enter such
settings with the keys on the front panel.
To switch to a series of setting screens, take the steps described below.
For details, see the operation manual furnished with this product.
L D b M
^ T h b
H
^ g f o
j E c I
^ j T L
M
^ i d h
F
^ i r b
H
^ o f d
h r
L D b F
▲ ▼key
F I H H
Power ON
Initial setting
(For 4 seconds)
Back to communications mode selection
H : TOHO communications protocol
Select a communications
setting mode
Set a communications protocol
(Setting mode selection
screen)
MODE key at least 2 seconds
Operation mode screen
MODE Key
MODE Key
MODE Key
MODE Key
MODE Key
Select a communications
parameters
Select a communications
speed
Select a communications
address
Select a communications
response delay
MODE Key
MODE Key
Select communications
mode switchover
When the settings are over, press the MODE key at least 2 seconds to go back to the operation mode.
The parameters indicated above are initial values.
