GP Series Portable Chillers Chapter 7: Appendix 77 of 93
Pure Water at >40°F
GPXC-20 GPXC-30 GPXC-40 GPXC-50
GPM DP (PSI) GPM DP (PSI) GPM DP (PSI) GPM DP (PSI)
0.5X Nominal 6 1.7 9 1.7 12 1.6 18 1.8
1.0X Nominal 12 5.9 18 6.1 24 5.8 36 6.4
2.0X Nominal 24 21.4 36 21.9 48 20.7 72 23.3
GPXC-70 GPXC-90 GPXC-140 GPXC-175
0.5X Nominal 24 1.7 30 1.8 36 1.7 48 1.8
1.0X Nominal 48 6.1 60 6.5 72 6.1 96 6.4
2.0X Nominal 96 21.9 120 23.5 144 22.1 192 23.6
GPXC-210
0.5X Nominal 72 1.7
1.0X Nominal 144 6.2
2.0X Nominal 288 22.7
Calculating Chiller Nominal Flow and Pressure to Process
• Flow rate: Obtain the flow reading from the appropriate pump curve.
• Pressure: Obtain a corresponding pressure reading from the pump curve you selected,
then subtract the one-pump pressure drop listed in the above table using the
appropriate chiller hp and flow rate.
