GP Series Portable Chillers Chapter 7: Appendix 64 of 93
GPAC-40
PERFORMANCE (NOMINAL DESIGN CONDITIONS)
COOLING CAPACITY 9.91 TONS ALTITUDE SEA LEVEL
COOLANT SUPPLY TEMPERATURE 50 °F COMPRESSOR POWER 10070 WATTS
AMBIENT AIR TEMPERATURE 95 °F EER 11.81 BTU/WATT
COOLANT WATER CONDENSER AIR FLOW 8458 CFM
COOLANT FLOW 24 GPM SOUND POWER LEVEL 87 dBA
UNIT PRESSURE DROP 7 PSID SOUND PRESSURE LEVEL @ 1 METER dBA
OPERATING PARAMETERS
COOLANT SUPPLY TEMPERATURE 20-80 °F COOLANT FLOW 12-48 GPM
AMBIENT AIR TEMPERATURE 60-115 °F MINIMUM LOAD 2.022 TONS
SPECIFICATIONS
COMPRESSOR SCROLL EVAPORATOR FILTER 20 MESH
COOLANT PUMP STAINLESS STEEL CENTRIFUGAL COOLANT CIRCUIT NON-FERROUS
EVAPORATOR BRAZED PLATE CAPACITY CONTROL HOT GAS BYPASS
CONDENSER ALUMINUM REFRIGERANT 6 LBS R-410A
CONDENSER FANS 32 INCH AXIAL FRAME GALVANIZED STEEL
CONDENSER FAN MOTOR 1 HP OAO, 1140 RPM PANELS POWDER COATED STEEL
RESERVOIR 40 GALLON POLYETHYLENE WEIGHT (OPERATING) 1090 LBS
POWER 460V/3PH/60HZ WEIGHT (SHIPPING) 760 LBS
CONTROL CIRCUIT 120 VDC ELECTRICAL ENCLOSURE NEMA 12
COMPRESSOR FULL LOAD AMPS 20 AMPS CONTROL MICROPROCESSOR
GPAC-50
PERFORMANCE (NOMINAL DESIGN CONDITIONS)
COOLING CAPACITY 15.19 TONS ALTITUDE SEA LEVEL
COOLANT SUPPLY TEMPERATURE 50 °F COMPRESSOR POWER 14882 WATTS
AMBIENT AIR TEMPERATURE 95 °F EER 12.25 BTU/WATT
COOLANT WATER CONDENSER AIR FLOW 12687 CFM
COOLANT FLOW 36 GPM SOUND POWER LEVEL 93 dBA
UNIT PRESSURE DROP 7 PSID SOUND PRESSURE LEVEL @ 1 METER dBA
OPERATING PARAMETERS
COOLANT SUPPLY TEMPERATURE 20-80 °F COOLANT FLOW 18-72 GPM
AMBIENT AIR TEMPERATURE 60-115 °F MINIMUM LOAD 3.016 TONS
SPECIFICATIONS
COMPRESSOR SCROLL EVAPORATOR FILTER 20 MESH
COOLANT PUMP STAINLESS STEEL CENTRIFUGAL COOLANT CIRCUIT NON-FERROUS
EVAPORATOR BRAZED PLATE CAPACITY CONTROL HOT GAS BYPASS
CONDENSER ALUMINUM REFRIGERANT 8 LBS R-410A
CONDENSER FANS 32 INCH AXIAL FRAME GALVANIZED STEEL
CONDENSER FAN MOTOR 2 HP OAO, 1140 RPM PANELS POWDER COATED STEEL
RESERVOIR 40 GALLON POLYETHYLENE WEIGHT (OPERATING) 1290 LBS
POWER 460V/3PH/60HZ WEIGHT (SHIPPING) 950 LBS
CONTROL CIRCUIT 120 VDC ELECTRICAL ENCLOSURE NEMA 12
COMPRESSOR FULL LOAD AMPS 30 AMPS CONTROL MICROPROCESSOR
