GP Series Portable Chillers Chapter 7: Appendix 67 of 93
GPAC-175
PERFORMANCE (NOMINAL DESIGN CONDITIONS)
COOLING CAPACITY 49.41 TONS ALTITUDE SEA LEVEL
COOLANT SUPPLY TEMPERATURE 50 °F COMPRESSOR POWER 48693 WATTS
AMBIENT AIR TEMPERATURE 95 °F EER 12.18 BTU/WATT
COOLANT WATER CONDENSER AIR FLOW 38061 CFM
COOLANT FLOW 118 GPM SOUND POWER LEVEL 98 dBA
UNIT PRESSURE DROP 7 PSID SOUND PRESS LEVEL @ 1 METER dBA
OPERATING PARAMETERS
COOLANT SUPPLY TEMPERATURE 20-80 °F COOLANT FLOW 60-240 GPM
AMBIENT AIR TEMPERATURE 60-115 °F MINIMUM LOAD 9.88 TONS
SPECIFICATIONS
COMPRESSOR SCROLL EVAPORATOR FILTER 20 MESH
COOLANT PUMP STAINLESS STEEL CENTRIFUGAL COOLANT CIRCUIT NON-FERROUS
EVAPORATOR BRAZED PLATE CAPACITY CONTROL HOT GAS BYPASS
CONDENSER ALUMINUM REFRIGERANT 24 LBS R-410A
CONDENSER FANS (3) 32 INCH AXIAL FRAME GALVANIZED STEEL
CONDENSER FAN MOTOR (3) 2 HP OAO, 1140 RPM PANELS POWDER COATED STEEL
RESERVOIR 140 GALLON POLYETHYLENE WEIGHT (OPERATING) 3870 LBS
POWER 460V/3PH/60HZ WEIGHT (SHIPPING) 2850 LBS
CONTROL CIRCUIT 24/120 VAC ELECTRICAL ENCLOSURE NEMA 12
COMPRESSOR RATED LOAD AMPS (2) @ 41.9 AMPS EACH CONTROL MICROPROCESSOR
GPAC-210
PERFORMANCE (NOMINAL DESIGN CONDITIONS)
COOLING CAPACITY 63.95 TONS ALTITUDE SEA LEVEL
COOLANT SUPPLY TEMPERATURE 50 °F COMPRESSOR POWER 63589 WATTS
AMBIENT AIR TEMPERATURE 95 °F EER 12.07 BTU/WATT
COOLANT WATER CONDENSER AIR FLOW 50748 CFM
COOLANT FLOW 153 GPM SOUND POWER LEVEL 99 dBA
UNIT PRESSURE DROP 7 PSID SOUND PRESS LEVEL @ 1 METER dBA
OPERATING PARAMETERS
COOLANT SUPPLY TEMPERATURE 20-80 °F COOLANT FLOW 72-288 GPM
AMBIENT AIR TEMPERATURE 60-115 °F MINIMUM LOAD 12.79 TONS
SPECIFICATIONS
COMPRESSOR SCROLL EVAPORATOR FILTER 20 MESH
COOLANT PUMP STAINLESS STEEL CENTRIFUGAL COOLANT CIRCUIT NON-FERROUS
EVAPORATOR BRAZED PLATE CAPACITY CONTROL HOT GAS BYPASS
CONDENSER ALUMINUM REFRIGERANT 32 LBS R-410A
CONDENSER FANS (4) 32 INCH AXIAL FRAME GALVANIZED STEEL
CONDENSER FAN MOTOR (4) 2 HP OAO, 1140 RPM PANELS POWDER COATED STEEL
RESERVOIR 140 GALLON POLYETHYLENE WEIGHT (OPERATING) 5160 LBS
POWER 460V/3PH/60HZ WEIGHT (SHIPPING) 3800 LBS
CONTROL CIRCUIT 24/120 VAC ELECTRICAL ENCLOSURE NEMA 12
COMPRESSOR RATED LOAD AMPS (2) @ 54.5 AMPS EACH CONTROL MICROPROCESSOR
