NUUO CMS - Manual (Page 16)

NUUO Central Management System
Getting Started with the NCS System
Page - 16
3. The configuration of NCS Alarm Server.
In the Configuration tab of Central Server window, enter the IP address of the SQL Server, and then enter and
confirm the password which sat when installed SQL Server. (see page 8)
Specify a URL at which to store all alarm images.
Select Run NCS Server when Windows starts up if you want NCS Server to startup automatically at Windows
startup
4. In the Main table of this window, check the server has been Start and click OK.
The NCS Server must be executed before the NCS Client can be executed.
NCS Client
To configure and execute the NCS Client:
1. In the Start menu, point to All Programs, point to NUUO Central Management Client, and then select NCS Client.
2. In the Central Login window, enter the IP address and port of the NCS Server PC. The default port is 5180.
3. Enter a user name and, if required, a password. The default user name is admin and the default password is
empty.
4. Click OK.
To activate software license key(s)
1. Open License Manager Tool in Help menu.
2. Select Activate tab, check the NCS system in On line network environment.
3. Insert the SN, SN file or dongle to activate license.
4. After software license is activated successfully, please restart NCS Client.
Please refer page 錯誤 錯誤 錯誤 錯誤! 尚未定義書籤 尚未定義書籤 尚未定義書籤 尚未定義書籤。 。 。 。 for advanced settings.
To start up NCS Client automatically:
1. In the Edit menu, select NCS Client Setting.
