1 Technical explanations
B 1091-1 GB-3213 17
Pos: 33 /Anleitungen/Motoren/B1091-1 Projektierungsleitfaden zur B1091/1. Technische Erläuterungen/1.7.3 Parametrierdaten 100 Hz- Kennlinie, IE1- und IE2- Motoren [B1091-1] @ 2\mod_1358264293717_388.docx @ 53581 @ 3 @ 1
1.7.3 Parameterisation data for the 100 Hz characteristic curve, IE1 and IE2 motors
Motor type
IE1
f
N
[Hz]
n
N
[rpm]
I
N
[A]
U
N
[V]
P
N
[kW]
cos φ Circuit
R
St
[ Ω]
63S/4 3D 100 2850 0.84 400 0.18 0.59 ∆ 68.00
63L/4 3D 100 2880 0.95 400 0.25 0.63 ∆ 47.37
71S/4 3D 100 2895 1.07 400 0.37 0.71 ∆ 39.9
71L/4 3D 100 2900 1.59 400 0.55 0.72 ∆ 22.85
80S/4 3D 100 2910 2.0 400 0.75 0.72 ∆ 15.79
80L/4 3D 100 2910 2.8 400 1.1 0.74 ∆ 10.49
90S/4 3D 100 2925 3.75 400 1.5 0.76 ∆ 6.41
90L/4 3D 100 2920 4.96 400 2.2 0.82 ∆ 3.99
100L/4 3D 100 2930 6.95 400 3.0 0.78 ∆ 2.78
100LA/4 3D 100 2950 7.46 400 4.0 0.76 ∆ 1.71
112M/4 3D 100 2945 11.3 400 5.5 0.82 ∆ 1.11
132S/4 3D 100 2955 16.0 400 7.5 0.82 ∆ 0.72
132M/4 3D 100 2965 19.6 400 9.2 0.79 ∆ 0.46
132MA/4 3D 100 2960 23.0 400 11.0 0.8 ∆ 0.39
Table 6: Parameterisation data for the 100 Hz characteristic curve, IE1 motors
Motor type
IE2
f
N
[Hz]
n
N
[rpm]
I
N
[A]
U
N
[V]
P
N
[kW]
cos φ Circuit
R
St
[ Ω]
80SH/4 3D 100 2930 1.9 400 0.75 0.7 ∆ 9.34
80LH/4 3D 100 2920 2.56 400 1.1 0.73 ∆ 6.3
90SH/4 3D 100 2930 3.53 400 1.5 0.79 ∆ 4.96
90LH/4 3D 100 2925 4.98 400 2.2 0.79 ∆ 3.27
100LH/4 3D 100 2955 6.47 400 3.0 0.78 ∆ 1.73
100AH/4 3D 100 2940 8.24 400 4.0 0.79 ∆ 1.48
112MH/4 3D 100 2950 11.13 400 5.5 0.82 ∆ 1.0
132SH/4 3D 100 2960 15.3 400 7.5 0.83 ∆ 0.6
132MH/4 3D 100 2965 19.5 400 9.2 0.79 ∆ 0.42
160MH/4 3D 100 2967 29.0 400 15.0 0.87 ∆ 0.256
160LH/4 3D 100 2975 35.7 400 18.5 0.86 ∆ 0.168
180MH/4 3D 100 2980 43.2 400 22 0.85 ∆ 0.115
180LH/4 3D 100 2980 55.5 400 30 0.88 ∆ 0.306
Table 7: Parameterisation data for the 100 Hz characteristic curve, IE2 motors
Legend
f
N
Nominal
frequency
I
N
Nominal current P
N
Nominal power Circuit ∆/Y circuit
n
N
Nominal speed U
N
Nominal voltage cos φ Power factor R
St
Resistance on
line
