4
Example 2 00 1 V A 3 2 230 LO 2001VA32-230-LO Hi-Flow ™ Globe Valve; 2-way, 3/4˝ NPT connec-
tion, linear plug, bronze body, 316 SS trim, reduced port 1/2˝ size.
Configuration 2
3 2-way
3-way
Valve Body
Action
00
01 Push-To-Close
Push-To-Open (2-way only)
Connection
Size
0
1
2
3
4
5
6
7
8 1/2˝ NPT
3/4˝ NPT
1˝ NPT
1-1/4˝ NPT
1-1/2˝ NPT (or Flange with LRF or HRF option)
2˝ NPT (or Flange with LRF or HRF option)
2-1/2˝ Flange (see options)
3˝ Flange (see options)
4˝ Flange (see options)
Valve Seat V
W
Single Seat (2-way only)
Double Seat (3-way only)
Valve Plug
Type
A
L
S
N
Linear
Linear Needle (2000 to 2002 only)
Equal Percentage (2000 to 2005 only)
Equal Percentage Needle (2000 to 2002 only)
Valve Body
Material
1
3
4 Ductile Iron
Bronze
316 SS
Trim
Material
2 316 SS
Actuator
220
221
222
223
230
231
233 Air-To-Lower, 20 in 2
Air-To-Lower, 45 in 2
Air-To-Lower, 45 in 2
Air-To-Lower, 80 in 2
Air-To-Raise, 20 in 2 (2-way only)
Air-To-Raise, 45 in 2 (2-way only)
Air-To-Raise, 80 in 2 (2-way only)
Needle Plug
Port Size
2
3
4
5
6
7
8
9 1/8˝ for Type N valve plug
3/16˝ for Type N valve plug
1/4˝ for Type N valve plug
5/16˝ for Type N valve plug
3/8˝ for Type N valve plug
1/32˝ for Type L valve plug
1/16˝ for Type L valve plug
3/32˝ for Type L valve plug
Options
A
L0
L1
Z
LRF
HRF
Positioner factory mounted
(specify positioner model)
Reduced port: 3/4˝ to 1/2˝ port size (2001 only)
Reduced port: 1˝ to 1/2˝ port size (2002 only)
Reduced port: 1˝ to 3/4˝ port size (2002 only)
Special operating range (2-10 psi, 10-18 psi)
Low Range Flange: Class 125 in Iron or Class 150 Bronze, 316 SS
body (for 1-1/2˝ and 2˝ sizes only, standard on 2-1/2˝, 3, and 4˝ size)
High Range Flange: Class 250 in Iron or Class 300 in Bronze, 316
SS body (for 1-1/2˝ to 4˝ sizes)
1.2 Catalog Numbers
Control Valves - Hi-Flow™ Series Model Chart
