Specifications
Power Supply:
SC4130/SC4151: 85 to 265 VDC / VAC 50 to 400 Hz.
SCL4130/SCL4151: 12 to 24 Vdc/Vac 50 to 400 Hz. ±20%
Isolation:
1500 VAC
Ambient Temperature Range:
Operating:
0° to 50° C (32° to 131° F)
Storage:
-40° to +80° C (-40° to +176° F)
Humidity Conditions: 0 to 90% rh up to 40°C non-condensing, 10 to
50% rh at 55°C non-condensing.
Linearity:
0.25%
Drift:
±0.02% per °C typical, ±0.05% maximum.
Maximum current output load:
600 ohms.
Maximum voltage output load:
20mA (500 ohms).
Input impedence - SC4130/SCL4130 - thermocouple:
1 Megohm.
RTD Search Current - SC4151/SCL4151 - RTD:
500µA maximum.
