Engineering Reference Table

MAINTENANCE
Since the sensing elements have no moving parts, only periodic cleaning
may be required. The sensing elements should be inspected for fouling of
the sensing holes as part of an annual preventative maintenance program.
Installations having viscous airborne particles may require more frequent
inspection. If the sensing holes on the elements have become fouled or
plugged, the following procedure is recommended. Caution, all instru-
ments must be isolated (removed) from the sensing lines prior to
performing the following cleaning procedure.

Backpurging: Connect clean/dry compressed air, set at a maximum
pressure of 25 psi, to the output pressure ports (total and/or static) of the
sensing element being cleaned. While purging the sensing element, wipe
the surface of the cylinder with a cloth or brush to loosen and remove all
contaminate buildup.

Velocity Versus Velocity Pressure

V = Velocity in feet per minute Pv = Velocity Pressure in inches H

2

O

Above Pv Values are Based on Standard Air Density of 0.075 lbm ft

3

which is Air at 68°F. 50% Relative Humidity, and 29.92˝ Hg.

The equation for converting air volume (Q) into velocity (V) and velocity pressure (Pv) is:

V = Q

A

PV = V

2

x p

C

[

[

Where
V = Velocity in fpm

C = 1096.7

Q = Flow in efm

p = Density of air in lb/ft

3

A = Area in ft

2

Pv = Velocity pressure in inches H

2

O

Cleaning: In applications where the sensing elements are subject
to viscous contaminants it is recommended that the surface be
washed with a cleaning agent. The cleaning agent used must be
suitable for use on the type of material the sensing element is con-
structed of (i.e. aluminum, stainless steel, etc.)
The Series FLST Duct Mounted Airflow Measurement Station is
not field serviceable and should be returned if repair is needed
(field repair should not be attempted and may void warranty). Be
sure to include a brief description of the problem plus any relevant
application notes. Contact customer service to receive a return
goods authorization number before shipping.
