P-Series Screw Pump Operation Manual
„„„„ „ FITTING KITS AND SPARE PARTS
Service Kits
X P016 / P017
P/N: 60P016 . . . . . . . . .For P016 pump.
P/N: 60P017 . . . . . . . . .For P017 pump.
X P-018-CPF
P/N: 60P016 . . . . . . . . .For P-018-CPF pump.
Hoses
X P016 / P017
P/N: 65P175 . . . . . . . . .Hose. 1.0 m, 1/4” BSP Female to 1/4” BSP Male connection.
P/N: 65P180 . . . . . . . . .Hose. 2.0 m, 1/4” BSP Female to 1/4” BSP Male connection.
P/N: 60I156 . . . . . . . . . .Hose. 1.5 m, 1/4” BSP Female to 1/4” BSP Male connection.
P/N: 60I157 . . . . . . . . . .Hose. 5.0 m, 1/4” BSP Female to 1/4” BSP Male connection.
X P-018-CPF
P/N: MPH-1 . . . . . . . . . .Hose. 1.0 m, CPF MP Male connection.
P/N: MPH-1.5 . . . . . . . .Hose. 1.5 m, CPF MP Male connection.
P/N: MPH-3 . . . . . . . . . .Hose. 3.0 m, CPF MP Male connection.
P/N: MPH-5 . . . . . . . . . .Hose. 5.0 m, CPF MP Male connection.
Adapters, Fittings and Plugs
X P016 / P017
P/N: 65N000 . . . . . . . . .Adapter. Extension tube, 120mm (Max. 350 bar / 5000 psi)
1/4" BSP Female to 1/4" BSP Male
P/N: 50-REP 615 . . . . .Adapter. Quick connector set, Female 1/4" BSP to 1/4" BSP
P/N: SPK-HPC-004 . . .Adapter. Banjo connector set for pump
P/N: 11-90109 . . . . . . .Fitting. 1/4” BSP Male to 1/4” NPT Female
P/N: 60R955 . . . . . . . . .Plug. 1/4” BSP Male
X P-018-CPF
P/N: MPM-PLUG . . . . .Plug. CPF Male.
P/N: 4013 . . . . . . . . . . . .Quick Test CPF Kit. (MPF-1/8QTF, MPF-1/4QTF, and MPF-1/2QTF)
P/N: 4015 . . . . . . . . . . . .BSP Test Kit. (MPF-1/8BSPF, MPF-1/4BSPF, MPF-3/8BSPF, and MPF-1/2BSPF)
Seals
X P016, P017, and P-018-CPF
P/N: 101549 . . . . . . . . .Bonded seal. For 1/2" BSP adapter.
P/N: 60R120 . . . . . . . . .Bonded seal. For 1/4” BSP adapter.
P/N: 60R122 . . . . . . . . .Bonded seal. For 1/8” BSP adapter.
Accessories
X P016, P017, and P-018-CPF
P/N: 65-R975 . . . . . . . .Auxiliary fluid reservoir. Includes vent valve lid.
P/N: 60R135 . . . . . . . . .Isolation valve.
P/N: 60P013 . . . . . . . . .Fine adjust knob
P/N: 60I104 . . . . . . . . . .Teflon tape. 1 roll.
P/N: 60R159 . . . . . . . . .Allen Key. 6 mm.
