Connection Diagrams
8
P-Series Screw Pump Operation Manual
Connection Diagrams
JOFRA REFERENCE INDICATORS
All parts are supplied as part of a pump system, or may be ordered separately. (All BSP connections require bonded seals.)
SPK-HPC-004
1/4" MBSP/1/4" MBSP
Banjo Connector
60R120
Bonded Seal
65R975
1/4" MBSP
Fluid Reservoir
60R135
1/4" MBSP
Isolation Valve
127401
1/4" FBSP/1/8" MBSP
60R164
1/4" FBSP/1/4" FNPT
Thread tape
required
CALIBRATION INSTRUMENTS
JOFRA
™
JOFRA
™
Handheld Pressure Calibrator
HPC500
F1
F2
F3
zero
127401
1/4" FBSP/1/8" MBSP
CALIBRATION INSTRUMENTS
Industrial Pressure Indicator MKII
IPI MKII
ZERO
MAX
MIN
CONFIG
ENTER
JOFRA
DPC-501
1
3
5
4
6
8
7
9
2
0
CLEAR
BACK
SETUP
SELECT
126025
1/4" FBSP/1/2" FBSP (to DPCJ Sensor)
65P175
1/4" BSP Pressure Hose
65N000
1/4" BSP Extension Tube
11-90109
1/4" MBSP/1/4" FNPT
60P013
1/4" MBSP
Fine Adjust
