MICRO-FLO
7.0 Programming
The Micro-Flo flowmeter uses a K-factor to calculate the flow rate and
total. The K-factor is defined as the number of pulses generated by the
paddle per volume of fluid flow. Each of the six different body sizes have
different operating flow ranges and different K-factors. The meter is
factory programmed for the correct K-factor of the body size included
with the meter.
The meter’s rate and total displays can be independently programmed to
display units in milliliters (ML), ounces (OZ), gallons (GAL), or liters
(LIT). Rate and total can be displayed in different units of measure. The
factory programming is in milliliters (ML).
The meter’s rate display can be independently programmed to display time
base units in minutes (Min), Hours (Hr), or Days (Day). The factory
programming is in minutes (Min).
For greater accuracy at a specific flow rate, the meter can be field cali-
brated. This procedure will automatically over-ride the factory K-factor with
the number of pulses accumulated during the calibration procedure. The
factory default settings can be re-selected at any time.
7.1 Field Calibration
Any body size/range can be field calibrated. Calibration will take into
account your specific application’s fluid properties, such as viscosity and
flow rate, and increase the accuracy of the meter in your application.
The Body Size/Range must be set for “S0” to enable the calibration mode.
Follow the programming instructions on pages 10 & 11 to reset the Body
Size/Range and perform the calibration procedure.
CLEAR
CAL /
ENTER While in the run mode, Press and hold ENTER then
press and hold CLEAR to display the K-factor.
6.6 Viewing the K-factor (pulses per unit)
0
ML
R Min
CLEAR
CAL /
ENTER Release ENTER and CLEAR to return to run mode.
181336
s1
s1
30-300 1
100-1000 2
200-2000 3
300-3000 4
500-5000 5
700-7000 6
181,336
81,509
42,051
25,153
15,737
9,375
Flow Range
(ml/min)
Body
Size
Pulses per
Gallon
21,535
13,752
6,646
4,157
2,477
Pulses per
Liter
47,909
Useful formulas
60 / K = rate scale factor
rate scale factor x Hz = flow rate in
volume per minute
1 / K = total scale factor
total scale factor x n pulses = total volume
