MODEL CODES FOR SRI990
0 9 9 I R S r e n o it i s o P g o l a n A
010411
Version
Single Acting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -B
Double Acting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -C
Position Transmitter (w/o pneumatic components) . . . . . . . . . . . . . . -T
Input
Signal Range 4 - 20 mA . . . . . . . . . . . . . . . . (h) . . . . . . . . . . . . . I
Not applicable (w/o Input Signal or Pneumatics) . . . . (f) . . . . . . . . . . . . . X
Additional Inputs/Outputs
Without Additional Inputs / Outputs . . . . . . . . . . (q) . . . . . . . . . . . . . . . . M
Position Feedback 4 - 20 mA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Q
Built-In Limit Switch
Without Built-In Limit Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . S
Inductive Limit Switch - Intrinsic Safe (Standard Version SJ2-N) . . . . . . . . . . . . . . . . . . T
Inductive Limit Switch - Intrinsic Safe (Security Version SJ2-SN). . . . . . . . . . . . . . . . . . U
Inductive Limit Switch (Three Wire Version) . . . . . . . . . . . . . (g) . . . . . . . . . . . . . R
Mechanical Switches (Micro Switches) / UL- and CSA-approved . . . (g) . . . . . . . . . . . . . V
Potentiometer Input (for Remote Mounting - main unit) . . . . . . . . (z) . . . . . . . . . . . . . D
Cable Entry
1/2"-14 NPT (with Adapter(s) M20x1,5 to 1/2"-14 NPT) . . . . . . . . . . . . . . . . . . . . . . . . . . 6
M20 x 1.5 With One Plastic Cable Gland . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Electrical Classification
Without Ex . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ZZZ
II 2 G EEx ia IIC T6 according to ATEX. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EAA
II 2 G EEx ia IIC T6 according to ATEX + Zone 20 Dust . . . . . . . . . . . . . . . . . . . . . . . . . . . . EDA
FM Approved Nonincendive For Class I, Division 2, Groups A, B, C, D, E, F & G
Hazardous Locations Indoors And Outdoors, NEMA 4X . . (k) . . . . . . . . . . . . . . . . . . . . . . . NFM
FM Approved For Intrinsic Safety Class I, Division 1, Groups A, B, C, D, E, F & G
Hazardous Locations Indoors And Outdoors, NEMA 4X . . (k) . . . . . . . . . . . . . . . . . . . . . . . FAA
CSA Approved For Intrinsic Safety Class I, Division 1, Groups A, B, C, D,
Hazardous Locations Indoors And Outdoors, NEMA 4X . (b)(k) . . . . . . . . . . . . . . . . . . . . . . CAA
GOST Approved For Intrinsic Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . GAA
Options
Pneumatic connection 1/4 - 18 NPT made of an additional manifold . (p) . . . . . . . . . . . . . . . . . . . . . . . -Y
Pneumatic connection G 1/4 . . . . . . . . . . . . . . . . . . . . . (p) . . . . . . . . . . . . . . . . . . . . . . . -R
Positioner free of copper and its alloys . . . . . . . . . . . . . . . . (i). . . . . . . . . . . . . . . . . . . . . . . . -C
Pneumatic Amplifier in the version "Spool Valve" . . . . . . . . . . . (e) . . . . . . . . . . . . . . . . . . . . . . . -S
Approved for SIL2 / SIL3 application . . . . . . . . . . . . . . . . . (l) . . . . . . . . . . . . . . . . . . . . . . . -Q
Version of Positioner according to VDI/VDE 3847. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -N
Feedback-Unit for Remote Mounting - Version of Position Transmitter only with a potentiometer . (f)(k) . . . . . . . . -H
Version of Position Transmitter with additional cable connections for solenoid-valve-connection. . (f) . . . . . . . . . -D
Certificate EN 10204-2.1 - Certificate of compliance with the order . . . . . . . . . . . . . . . . . . . . . . . . . . . -1
Stainless Steel Housing . . . . . . . . . . . . . . . . . . . . . . . (n) . . . . . . . . . . . . . . . . . . . . . . . -Z
Stainless Steel Housing without SST gauges. . . . . . . . . . . . . (n) . . . . . . . . . . . . . . . . . . . . . . . -Z1
Top Mounting version of SRI990 with built-in linear potentiometer . . . . . . . . . . . . . . . . . . . . . . . . . . . -W
Tag No. Labeling Stamped With Weather Resistant Color . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -G
Tag No. Labeling Stainless Steel Label Fixed With Wire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -L
(a) Only with (Version -B OR -C) AND (Input -I) AND (Additionnal Input/Output - M) AND (Built-In Limit Switch -S) AND
(Electrical Classification -ZZZ)
(b) On request (d) Not released (e) Only with Version -C (f) Only with Version -T
(g) Not available with Electrical Classification EAA, ED3, NFM, FAA, CAA, GAA
(h) Not available with Version -T
(i) Available with (Version: B) OR with (Version: C) AND (Optional Features: S)
(j) Not with (Optional Features -U OR -N OR -H OR -D OR -Z OR -Z1)
(k) Not available with Additional Inputs/Outputs Q (l) Only available for Version single-acting -B
(n) Available WITH (Version: C) AND (Built-in Limit Switch: S) AND (Electrical Classification: ZZZ, EAA, GAA) AND
(Optional Features: S) OR WITH (Version: T) AND (Built-in Limit Switch: S) AND (Electrical Classification: ZZZ,
EAA, GAA) OR WITH (Version: B) A
(p) One of the option -Y or -R is mandatory to be select
(q) WITH (Version: B, C) OR WITH (Version: T) AND (Input: X) AND (Optional Features: H)
OR WITH (Version: T) AND (Input: X) AND (Built-in Limit Switch: T, U, R, V)
(z) Not available with Electrical Classification FAA, NFM, CAA
Model Codes for SRI990
