Transmitter Connections
For connecting to Badger Meter transmitters, refer to the literature for your specific transmitter and to Table 2 below The
Connections column refers to the wires on the transmitter The numbers in parenthesis refer to the terminal numbers
on the ER-6/R Connect the wire coming from the transmitter to the corresponding terminal number for the ER-Series
Remote models
Transmitter Connections
MS-E1 Black (1) Red (2)
MS-E5 Black (1) Red (2)
PFT-1E Terminal 6 (1) Terminal 5 (2)
PFT-4E Terminal 6 (1) Terminal 5 (2)
PM-5 Black (1) Red (2)
Table 2: Transmitter connections
OPERATION
34675890
Figure 4: Total display
Total Display
Total Display indicates the present count value, which is equal to the number of pulses received (since the last reset)
Reset Key
While the Total Value displays, press RST to reset the value to zero
TROUBLESHOOTING
Problem Possible Causes Remedies
Screen is blank Battery is dead Replace battery
Will not count 1 Broken or defective wiring
2 Improperly connected
3 Transmitter defective 1 Check wiring
2 Check connections
3 Repair or replace transmitter
Cannot reset from front panel Reset enable is active Check connection between terminals 1 and 5
Erroneous readings Defective transmitter Repair or replace transmitter
Table 3: Troubleshooting
For further assistance, call our Technical Support Staff at 1-800-876-3837
Installation & Operation Manual
Page 7 February 2013
