INTRODUCTION
The B2800XP flow monitor is a state-of-the-art digital signal processing flow monitor designed to provide the user with
exceptional flexibility at a very affordable price Though designed for use with Blancett flow meters, this display can be used
with almost any flow meter producing a low amplitude AC output or contact closure signals
The B2800XP flow monitor is capable of accepting a low level frequency input for calculating flow rate and total These
calculations can then be displayed in the desired units of measurement All B2800XP flow monitors come pre-calibrated from
the factory, if ordered with a Blancett flow meter If required, however, it can easily be reconfigured in the field The monitor’s
large eight digit by 0 50 inch numeric liquid crystal display makes extended range viewing practical The second eight digit by
0 25 inch alphanumeric display provides for selectable units viewing in run mode and prompts for variables in program mode
Finally, the user can choose between displaying rate, total or alternating between both rate and total
Figure 1: B2800XP flow monitor
Programming
Buttons
MENU ENTER
Programming Manual
