LMMA METER WITH CTR INDEX AND RIOTRONICS PULSER
METER SIZE INDEX TYPE
DRIVE VALUE
Cu. Ft./Rev.
INDEX RES
Cu. Ft.
# OF INDEX
DIALS
PROGRAMMER
DESCRIPTION
SUBCOUNTS
8C CTR 5 100 5 5 CuFt REM (100:5) 1 2
11C CTR 5 100 5 5 CuFt REM (100:5) 1 2
15C CTR 5 100 5 5 CuFt REM (100:5) 1 2
2M CTR 5 100 5 5 CuFt REM (100:5) 1 2
3M CTR 5 100 5 5 CuFt REM (100:5) 1 2
5M CTR 5 100 5 5 CuFt REM (100:5) 1 2
7M CTR 5 100 5 5 CuFt REM (100:5) 1 2
11M CTR 5 100 5 5 CuFt REM (100:5) 1 2
16M CTR 50 100 6 50 CuFt REM (100:6) 10 1
23M CTR 50 100 6 50 CuFt REM (100:6) 10 1
38M CTR 50 100 6 50 CuFt REM (100:6) 10 1
56M CTR 50 100 6 50 CuFt REM (100:6) 10 1
LMMA METER WITH TC (Temperature compensated) INDEX AND RIOTRONICS PULSER
8C TC 25 100 5 25 CuFt REM (100:5) 10 1
11C TC 25 100 5 25 CuFt REM (100:5) 10 1
15C TC 25 100 5 25 CuFt REM (100:5) 10 1
2M TC 25 100 5 25 CuFt REM (100:5) 10 1
3M TC 25 100 5 25 CuFt REM (100:5) 10 1
5M TC 25 100 5 25 CuFt REM (100:5) 10 1
7M TC 25 100 5 25 CuFt REM (100:5) 10 1
11M TC 25 100 5 25 CuFt REM (100:5) 10 1
16M TC 250 100 6 250 CuFt REM (100:6) 100 0
Programming the ORION® Gas Endpoint
