Badger Meter Compound Series - Manual (Page 20)

Reinstalling the Cover Assembly
Badger Meter recommends that a new O-ring be used after each teardown and reassembly of the cover assembly To assure
a tight seal, make sure O-ring is positioned correctly on the housing and that the O-ring and cover assembly are clean and
free of dirt or residual traces of old O-ring material If necessary, use silicone grease to help retain the O-ring and to serve as a
lubricant in reassembling it to the housing
Cover bolts should be tightened in a crisscross pattern similar to Turbo head bolts Torque 2" and 3" cover assembly bolts to
16…18 ft-lb Torque the bolts for the 4" and 6" cover assemblies to 35…40 ft-lb
SPECIFICATIONS
Compound Series Model 2" (50 mm) 3" (80 mm) 4" (100 mm) 6" (150 mm)
Meter Flanges, Class 150
2" elliptical or round 3" round 4" round 6" round
(50 mm) (80 mm) (100 mm) (150 mm)
Typical Operating Range 0 5…200 gpm 0 5…450 gpm 0 75…1000 gpm 0 75…2000 gpm
(100% ± 1.5%) (0 1…45 m 3 /h) (0 1…102 m 3 /h) (0 17…227 m 3 /h) (0 17…454 4 m 3 /h)
Low Flow Registration
(97% minimum)
0 25 gpm (0 06 m 3 /h) 0 25 gpm (0 06 m 3 /h) 0 375 gpm (0 09 m 3 /h) 0 375 gpm (0 09 m 3 /h)
Maximum Continuous Flow 170 gpm (38 3 m 3 /h) 400 gpm (90 3 m 3 /h) 800 gpm (181 6 m 3 /h) 1500 gpm (340 5 m 3 /h)
Pressure Loss at Maximum
Continuous Flow 5 4 psi at 170 gpm 6 0 psi at 400 gpm 11 0 psi at 800 gpm 9 3 psi at 1500 gpm
(0 38 bar at 38 3 m 3 /h) (0 41 bar at 90 3 m 3 /h) (0 75 bar at 181 6 m 3 /h) (0 64 bar at 340 5 m 3 /h)
Crossover Flow Rate, Typical 12 gpm 12 gpm 20 gpm 30 gpm
Pressure Loss at Crossover 3 5 psi (0 24 bar) 4 0 psi (0 28 bar) 4 0 psi (0 28 bar) 5 0 psi (0 35 bar)
Minimum Crossover Accuracy 97% 97% 97% 95%
Maximum Operating Pressure 150 psi (10 bar)
Maximum Operating
Temperature
105° F (41° C)
Test Plug 1-1/2" 2"
Materials
Meter Housing & Cover Lead-free bronze alloy
Turbo Cast Head Lead-free bronze alloy
Nose Cone & Straightening Vanes Thermoplastic
Rotor Thermoplastic
Rotor Radial Bearings Lubricated thermoplastic
Rotor Thrust Bearing Sapphire jewels
Rotor Bearing Pivots Passivated 316 stainless steel
Calibration Mechanism Stainless steel & thermoplastic
Measuring Chamber & Disc Thermoplastic
High Flow Valve Stainless steel & thermoplastic
Magnets Ceramic
Register Lens Glass
Register Housing & Cover Thermoplastic or bronze
Trim Stainless steel
Drain Plug (3/4") Stainless steel or lead-free bronze alloy
Test Plug Stainless steel or lead-free bronze alloy
