STEREO INPUT
CONNECTORS
This panel carries the input TRS
jacks for the stereo inputs located
on the master section of the
console.
There are 4 returns each with a left
and a right input.
If a mono source is used then it
should be plugged into the left
input. This is normalled over to
the right input causing the signal
to travel through the left and right
signal paths of the return. If a plug
is inserted into the right input the
normalled connection is broken.
