ULTIMA COMPACT Condensing Units
20
Condensers & Condensing Units
Technical Manual : Part No 904-047 V1.4.0_02_2013
General Specification
MECHANICAL DATA
UCCU160D-4/2 UCCU180D-6/2 UCCU200D-6/2 UCCU225D-6/2 UCCU250D-6/2 UCCU275D-8/2
Duty - Cooling
Cooling Only (1) kW 158.2 195.2 215.9 243.8 264.0 298.4
Nominal Input (1) kW 46.6 51.6 59.8 69.1 78.0 93.4
EER (2) 3.39 3.79 3.61 3.53 3.39 3.19
Capacity Steps % 0-25-50-75-100 0-20-40-50-60-80-100 0-20-40-50-60-80-100 0-20-40-50-60-80-100 0-25-50-75-100 0-20-40-50-60-80-100
Capacity Split - CCT1 / CCT2 % 50 / 50 50 / 50 50 / 50 50 / 50 50 / 50 50 / 50
Dimensions - H x L x W mm 2100x2415x1850 2100x3220x1850 2100x3220x1850 2100x3220x1850 2100x3220x1850 2180x4700x2200
Weight - Machine kg 1370 1760 1760 1880 1880 2350
Weight - Operating kg 1410 1810 1810 1930 1930 2410
Construction - Material / Colour Plain Galvanised Steel Base with Galvanised Sheet Steel, Epoxy Baked Powder Paint Superstructure- Light Grey (RAL 7035)
Condenser Copper Tube/ Aluminium Fins - Air Cooled
Face Area (Total) m² 5.20 7.80 7.80 7.80 7.80 11.20
Nominal Airflow m³/s 12.80 19.20 19.20 19.20 19.20 24.80
Fan & Motor Sickle Bladed Fan
Quantity 4 6 6 6 6 8
Diameter mm 630 630 630 630 630 710
Maximum Speed rpm 1100 1100 1100 1100 1100 900
Compressor Tandem Scroll
Quantity 4 4 4 4 4 4
Oil Charge Volume (Total) l 4 x 6.2 4 x 8.0 2 x 8.0 + 2 x 6.2 4 x 8.0 4 x 8.0 4 x 8.0
Oil Type Polyol Ester
Refrigeration (3) Dual Circuit
Holding Charge Helium to 6.9 barg
Refrigerant Type R407C
Recommended Charge (Total) kg 20 + 20 30 + 30 30 + 30 30 + 30 30 + 30 41 + 41
Connections (4)
Liquid Line in 1 1/8 1 1/8 1 3/8 1 3/8 1 3/8 1 5/8
Suction Line in 2 1/8 2 1/8 2 1/8 2 1/8 2 1/8 2 5/8
QUIET DQ UCCU160DQ-6/2 UCCU180DQ-6/2 UCCU200DQ-6/2 UCCU225DQ-8/2 UCCU250DQ-8/2 UCCU275DQ-10/2
All data as D Model except:
Cooling Duty (1) kW 164.9 190.1 212.9 246.0 266.5 299.7
Nominal Input (1) kW 43.4 53.9 61.3 68.0 76.6 93.1
EER (2) 3.80 3.53 3.47 3.62 3.48 3.22
Dimensions, H x L x W mm 2100x3220x1850 2100x3220x1850 2100x3220x1850 2100x4025x1850 2100x4025x1850 2180x5550x2200
Weight - Machine kg 1580 1690 1690 2050 2050 2630
Weight - Operating kg 1630 1740 1740 2120 2120 2700
Condenser Face Area (Total) m 2 7.80 7.80 7.80 10.40 10.40 14.00
Nominal Airflow m³/s 14.88 14.88 14.88 19.84 19.84 24.50
Condenser Fans, number 6 6 6 8 8 10
Maximum Fan Speed rpm 900 900 900 900 900 750
Refrigerant Charge (Total) (3) kg 30 + 30 30 + 30 30 + 30 40 + 40 40 + 40 41 + 41
SUPER QUIET DSQ UCCU160DSQ-6/2 UCCU180DSQ-6/2 UCCU200DSQ-8/2 UCCU225DSQ-8/2 UCCU250DSQ-8/2 UCCU275DSQ-12/2
All data as D Model except:
Cooling Duty (1) kW 159.9 186.3 213.9 241.5 261.3 299.9
Nominal Input (1) kW 45.8 55.7 60.8 70.3 79.4 93.1
EER (2) 3.49 3.35 3.52 3.44 3.29 3.22
Dimensions, H x L x W mm 2100x3220x1850 2100x3220x1850 2100x4025x1850 2100x4025x1850 2100x4025x1850 2180x6400x2200
Weight - Machine kg 1600 1710 1960 2070 2070 2930
Weight - Operating kg 1650 1760 2030 2140 2140 3010
Condenser Face Area (Total) m 2 7.80 7.80 10.40 10.40 10.40 16.80
Nominal Airflow m³/s 11.76 11.76 15.68 15.68 15.68 20.40
Condenser Fans, number 6 6 8 8 8 12
Maximum Fan Speed rpm 750 750 750 750 750 570
Refrigerant Charge (Total) (3) kg 30 + 30 30 + 30 30 + 30 40 + 40 40 + 40 50 + 50
(1) Nominal Cooling Duties based on 5°C Evaporating temperature and 30°C ambient.
(2) EER is the Cooling duty  compressor input power.
(3) Unit supplied with a holding charge of Helium, the refrigerant charge is suitable for upto 10 metres of interconnecting pipework, additional refrigerant must be added for longer
pipe runs.
(4) Suitable For Brazed Connections.
