Airedale Ultima Compact Condensing Unit 30kW - 450kW - Manual (Page 16)

ULTIMA COMPACT Condensing Units
16
Condensers & Condensing Units
Technical Manual : Part No 904-047 V1.4.0_02_2013
Performance Data
SOUND DATA
Global Sound Level
Quiet - SQ & DQ Models
Sound
Measurement Overall
dB(A)
Frequency (Hz) dB
63 125 250 500 1000 2000 4000
UCCU30SQ-1/1
UCCU30DQ-1/1 Power 78 70 75 74 74 75 71 67
Pressure @ 10m 46 38 43 42 42 43 39 35
UCCU40SQ-1/1
UCCU40DQ-1/1 Power 78 70 75 74 74 75 71 67
Pressure @ 10m 46 38 43 42 42 43 39 35
UCCU50SQ-2/1
UCCU50DQ-2/1 Power 80 82 82 78 76 77 73 66
Pressure @ 10m 48 50 50 46 44 45 41 34
UCCU60SQ-2/1
UCCU60DQ-2/1 Power 80 82 82 78 76 77 73 66
Pressure @ 10m 48 50 50 46 44 45 41 34
UCCU70SQ-2/1
UCCU70DQ-2/1 Power 80 82 82 78 76 77 73 66
Pressure @ 10m 48 50 50 46 44 45 41 34
UCCU75DQ-2/1
Power 77 75 80 73 75 74 68 61
Pressure @ 10m 45 43 48 41 43 42 36 29
UCCU80SQ-2/1
UCCU80DQ-2/1 Power 80 82 82 78 76 77 73 66
Pressure @ 10m 48 50 50 46 44 45 41 34
UCCU100DQ-2/1
Power 77 73 80 73 75 74 68 62
Pressure @ 10m 45 41 48 41 43 42 36 30
UCCU110DQ-4/2
Power 83 86 85 80 78 80 76 70
Pressure @ 10m 51 54 53 48 46 48 44 38
UCCU125DQ-3/1
Power 80 75 84 82 77 76 70 64
Pressure @ 10m 48 43 52 50 45 44 38 32
UCCU130DQ-4/2
Power 83 85 85 83 78 80 76 70
Pressure @ 10m 51 53 53 51 46 48 44 38
UCCU150DQ-4/1
Power 81 76 85 82 79 77 71 65
Pressure @ 10m 49 44 53 50 47 45 39 33
UCCU160DQ-6/2
Power 85 87 86 84 80 81 77 71
Pressure @ 10m 53 55 54 52 48 49 45 39
UCCU180DQ-6/2
Power 85 87 89 84 80 82 77 72
Pressure @ 10m 53 55 57 52 48 50 45 40
UCCU200DQ-6/2
Power 86 87 88 86 81 82 77 71
Pressure @ 10m 54 55 56 54 49 50 45 39
UCCU225DQ-8/2
Power 87 88 89 87 82 83 79 73
Pressure @ 10m 55 56 57 55 50 51 47 41
UCCU250DQ-8/2
Power 87 88 89 87 82 83 79 73
Pressure @ 10m 55 56 57 55 50 51 47 41
UCCU275DQ-10/2
Power 86 78 85 78 84 81 78 72
Pressure @ 10m 54 46 53 46 52 49 46 40
UCCU300DQ-10/2
Power 86 79 86 79 85 82 78 72
Pressure @ 10m 54 47 54 47 53 50 46 40
UCCU330DQ-12/2
Power 86 79 87 80 85 82 77 71
Pressure @ 10m 54 47 55 48 53 50 45 39
UCCU360DQ-12/2
Power 87 79 87 80 86 82 77 71
Pressure @ 10m 55 47 55 48 54 50 45 39
UCCU400DQ-14/2
Power 87 80 87 81 86 83 78 72
Pressure @ 10m 54 47 54 48 53 50 45 39
UCCU450DQ-14/2
Power 87 80 88 81 87 83 78 72
Pressure @ 10m 54 47 55 48 54 50 45 39
1 dB(A) is the overall sound level, measured on the A scale.
2 All sound data measured at nominal conditions: 5°C Evaporating temperature and 30°C ambient.
The Sound Pressure data quoted is only valid in free field conditions, where the unit is installed on a reflective base. If
the equipment is placed adjacent to a reflective wall, values may vary to those stated, typically increasing by 3dB for
each side added.
