The Reading View Panel (Main Panel)
The main panel of Alpha Link 600 comes with four view windows, V1, V2, V3 and V4
(Figure 12), allowing you to monitor 4 transmitters simultaneously, or one transmitter in
three different views.
Figure 12 : View Window
1. Data Reading View
Parameter, current reading,
temperature reading and ATC/MTC
setting.
1. Unique Instrument ID
2. Caption. Double-
click on this to input
your caption.
3. Measurement Mode
5. Temperature
Reading
6. Status of Transmission
4. Current Reading
