18

SPECIFICATIONS

Tube capacity

6 (large and small in any combination)

24 mini tubes (when using the FHB61 mini tube holder)

96 x 15ml tubes (in holder)

48 x 50ml tubes (in holder)

Maximum temperature*

100°C

Minimum temperature

10°C above ambient

Temperature selection

Digital

Adjustable rotation speed

0; 5 to 20 rpm

Adjustable rocking platform (optional)

30 opm recommended

Temperature display

LED

Temperature set point resolution

0.1°C

Temperature sensor

PRT

Temperature stability in the chamber

≤1.0°C

Temperature stability in the tubes

±0.1°C

Temperature uniformity in the chamber#

±1.5°C

Temperature uniformity in the tubes#

±1.0°C

Temperature accuracy

±0.3°C

External dimensions (W x D x H)

385 x 285 x 555mm

Internal dimensions (W x D x H)

260 x 210 x 330mm

Electrical supply

230V, 50/60Hz

120V, 50/60Hz

Power

750W

Net weight

20kg

Shipping weight

24kg

Note: The HB-1D includes a pre-set, re-settable over-temperature cut-out.
#Temperature measured in the centre of each tube.

*Large tubes are fitted with seals suitable for use up to 70°C. For higher temperatures, seals part

number 6101488 are required.

For the hybridisation tubes see the list under Spares and Accessories
