Seametrics iMAG-Series User Manual
Page 4
GENERAL INFORMATION
Page 2
FEATURES Continued
Flanges, 150 lb. ANSI pattern
Equalization lug
Rate and total indicator
iMAG 4600-0300
Glass filled molded plastic liner
Power/Output cable port access, tamper-sealed
316SS electrodes
Powder-coated ductile cast iron body & electronics housing
Security seal & cross-drilled screws (2) for tamper-evidence
iMAG 4600-0400
iMAG 3600-0400
(Remote indicator)
Welded steel epoxy-coated flow tube
Flanges, 150 lb. ANSI pattern
Santoprene/Polypropylene Liner
Power/Output cable port access
Equalization lug
Powder-coated ductile cast iron electronics housing
Rate and total indicator with protective cover and keypad sensors
316SS electrodes
Security seal & cross-drilled screws (2) for tamper-evidence
