GENERAL INFORMATION
The iMAG-Series is the most economical flanged
electromagnetic flowmeter on the market. It is used in 3” to 12”
pipe in municipal or industrial water, wastewater, pump stations
and packaged plant applications. The iMAG has no moving
parts and electrodes are designed to discourage fouling. This
magmeter requires no maintenance in applications where
debris would impede mechanical meters. There are no parts to
wear out. Minimal straight pipe requirements allow iMAG-Series
meters to be used in piping configurations where there is little
space between the meter and an elbow.
iMAG-Series meters are rated IP68 for applications where the
meter may be under water up to a depth of 10 feet (3 meters)
for prolonged periods of time.
Rate and total indication are standard. Rate and total units and
pulse output are settable via the front panel touch key pad by
the user.
The iMAG can be externally powered with 9-36 Vdc at 30 mA
average.
The standard 20-foot (6 meter) cable also provides outputs for
use with a variety of Seametrics and other displays and controls
for remote reading, data logging and telemetry applications.
4-20mA passive current loop and high frequency outputs are
optional. The iMAG 3600 remote display meter can be supplied
with an optional internal AC power supply.
FEATURES
Protective Cover with Magnetic Seal
Light Sensor Keypad
Multifunction Display
