- 1 -
The camera provided high-quality image using SONY Wide Dynamic 1/3” Super-HADII PS
960H CCD and digital signal processing LSIs.
Features:

1/3" Super-HADII PS 960H CCD

Super high-resolution of 650TV lines

Wide Dynamic Range (~x512)

Excessive High-Light Compensation

Back Light Masking (MAX. 15 area)

2D-NR, 3D-NR (DNR Demo)

Day & Night(Auto, Manual, External, Filter delay)

0.4 lux(Color), 0.04 lux(B/W), 0.001 lux(Low-Shutter) @ F1.4 Sensitivity

Sens-Up (~x32)

Various Detection Method (zone detection, motion trace, face trace, mine
area, absent detection, cross object counting, entrance counting)

Scene Change Detection

Various Alarm Method (Period, Snooze, Polarity Select)

Frame Control (Auto, 1~7 sec)

Privacy Mask or Mosaic (MAX. 15 area/4-point polygonal/transparency)

Digital PTZ

White Pixel Remove

Back Light Compensation

Digital Effect (H/V reverse, 180 degree rotate, inverse, freeze)

System Lock (4-Digit password)

Auto Electronic Shutter [1/50 ~ 1/100,000] and manual electronic shutter
modes [1/50 ~ 1/10,000]

C/CS, back-focus cam for easy adjustment

Auto and Manual white balance modes

Support Line-Lock external synchronization

RS-485 Remote camera control

On Screen Display (OSD)

Compatible with Video, DC type lenses with OSD select

Quick connect for Video or DC lens with 4-pin connector

User Certified / Listed Class 2 power source only

Operates in 12VDC or 24VAC
INTRODUCTION
IMPORTANT : The user of this camera is responsible for
checking and complying with local, state, and federal laws
and statutes concerning the recording and monitoring of
audio signals.
