Revo REXT650-1 User Manual
Page 6

INTRODUCTION
1
CAMERA CONNECTIONS
2
WALL BRACKET MOUNTING
2
CAMERA OVERVIEW
3
CONTROL AND CONNECTIONS/DAY&NIGHT I/O/
ALARM OUT TERMINALS
9
WIRING DIAGRAM
10
HOUSING KIT SPECIFICATIONS
10
CAMERA SPECIFICATIONS
11
CAMERA ADJUSTMENT
3
- v -
TABLE OF CONTENTS
Installation of the camera must be performed by qualified service personnel in accordance
with all local and national electrical and mechanical codes.
Carefully remove the color camera and its accessories from the carton
and verify that they were not damaged in shipment.
The contents of the package includes:
1. CAMERA HOUSING KIT
2. This manual
3. L-wrench (5mm) --------------- 1ea
(2.5mm) ------------- 1ea
4. ANCHOR (5mm) --------------- 4ea
CONTENTS OF PACKAGE
