2.2 Base Installation, continued
4
1. Make mounting holes and cable hole in the place (ceiling) to which this dome
camera is installed using the supplied template sheet.
Warning: The total mass of the main unit is approx 1.3kg. Check whether the
ceiling to which the Dome Camera is installed is strong enough to hold the unit
mass. If not, the Dome Camera could fall, causing injury.
Mounting Screw
M6x35 (4x)
Plastic Anchor (4x)
CEILING
Rubber
Washers(4x)
Template Sheet
Dome Cover
Dome Base
[Installation]
TEMPLATE SHEET
145.0
29.0
-
5
7
t n
l
4
mo
n
e
. (
i g h
o )
u
140
0 .
90.0
(cable
hole
)
30.0
14
5.
0
o
45
4
