6
5. OPERATION
5.1 Power On
1. To power-up, connect to a DC 12V power input connector.
NOTE 1: Booting time (does not include SD card checking process) is about thirty seconds.
NOTE 2: Booting time may be slightly longer if an image file error occurs, because the
system
will automatically try to fix this situation.
NOTE 3: Implementing SD card checking process, the system will temporarily be busy and
may result in delays or a short-term frozen operating time display .
2. After power on, the system auto enters live monitoring. When the system is currently
under schedule recording, it auto enters record mode.
3. “ ” icon shown on the status line, indicates that the SD card is operating
normally.
4. When the SD card is not inserted or a problem occurs on the SD card, the “ ”
icon will be shown on the display. Please re-format before proceeding.
5. You can play while the SD card is “read only”, but you cannot record.
6. After power-loss the system auto returns to the previous recording mode.
Do not withdraw the SD card while booting. It may destroy the data stored within the SD
card.
5.2 Live Mode
Live mode is the default setup after system start-up.
① Time Display: System Date and Time.
② Video Indicator: Video icon will circle around as shown by the illustration
below.
О О О
