Model 4069 ProfileIR TM User Manual Operation
Research, Inc. 20
OPTIONS
SCREEN
The OPTIONS screen displays the status of each of the alarms. The
dashed line (-----) indicates no alarm. Alarms are of one of two types,
either a Critical or a Minor alarm. A Critical alarm will turn the
system to off , dropping out the heater contactor. It is due to an
abnormal condition that could damage equipment or harm personnel.
A Minor alarm puts the system in a waiting state where the power level
to the heaters is changed to 0%; once the condition has cleared the
power level returns to the pre-alarm level.
PYROMETER An option Pyrometer (optical temperature sensor) is
available for the 4069P. The pyrometer when installed and enabled
will display the temperature measured on the MAIN screen.
PYROMETER DISPLAY The temperature read by the Pyrometer
Option can be displayed in either degrees Fahrenheit or degrees Celsius
by making the appropriate selection here.
MOTION DETECTION An optional motion detection sensor is
available for the 4069P. The motion detection feature, when installed,
can be enabled and disabled by this selection. It consists of a Teflon
