Operating manual
5301 Series Load Pins
9
mV/V Output
(4 – wire)
0…20mA
(3 – wire)
4…20 mA
(2 – wire)
0…10 VDC
(3 – wire)
Colour coding
cable
Power
supply: UB+
1
1
1
1
brown
Power
supply:
0V/UB-/S-
3
3
3
3
blue
Supply
Relay: (UR)
2
2
withe
Supply
Relay: (0V)
4
3
black / blue
Signal: S+
4
4
-
4
black
Signal: S_
2
-
-
-
white
Schirm
housing
housing
housing
housing
Schirm
Switch: 2 switching outputs
n- switching
p- switching
CANopen
Round connector
M12x1, 5-polig
4
3
Shield
1
UB+ (CAN V+)
2
UB- (CAN GND)
3
Bus-Signal CAN-High
4
Bus-Signal CAN-Low
5
Power supply: UB+
1
Power supply: 0V
3
Switching output: S1
4
Switching output: S2
5
Shield
Housing
5
1
2
