20
6. Specifications
Pressure Module Dependent. Operates with Fluke 700 Series
Ranges: Modules
T/C Ranges: J, K, T, E, R, S, N, B, L, U including – 10 to 70mV
RTD Ranges: Pt 385 (100, 200, 500, 1000 ohms)
Pt 392, JIS, Ni120, CU10, YSI400
Ohms Ranges: 0 to 400.00 and 400.0 to 3200.0
mA Range: 0 to 24.000 mA
Voltage: (Low) Input 0-20.000 V, Output 0-20.000 V
(High) Input only 0-250 VDC or VAC
Frequency: Source Measure
CPM 2.0-1000.0 0.0-1000.0
Hz 0-1000 0.0-1000.0
kHz 1.0-10.0 0.0-10.00
Continuity: 0 to 400.0 ohms, audible tone when under 10 ohms
Accuracy: T/C Type J: ±.3°C ±10
µV (±0.4°C total error)
RTD PT100: ±.1°C ±.075
Ω (±0.3°C total error)
Ohms (400): ±0.1
Ω
Ohms (3200): ±1.0
Ω
mA Compliance: Up to 1000
Ω load
Voltage Drive
Capability:
1 mA
RTD IEX-range: 0.01 mA to 3 mA
RTD Frequency
Response:
10 mS – works with all pulsed XMTR’s
Oper. Temp: -10°C to 50°C
Storage Temp: -40°C to 60°C
Loop Power: 4 AA alkaline batteries, 25 hours typical operating
time
Size: 7.5" x 4" x 1.5"
3. Remove one fuse at a time and check conti-
nuity using an ohmmeter. A good fuse will
read 10 ohms or less. A blown fuse will have
a very high reading and generally show as
an open circuit.
4. If a blown fuse is found replace with the
enclosed spare fuse.
5. To order more fuses contact Martel
Electronics and order part no. 3535039.
