ending setpoint location. Example: if
you have all 9 setpoints stored but
only want to step through the first 3
then enter “3” for this question.

c. The next screen prompts you to enter

the dwell time from 5 to 500 seconds.
Simply enter a number in that range.
Then press the “Enter” key.

d. Auto-step will begin.
e. To exit auto-step press “CE” key or

enter a value.

4. Manual Stepping

The MC1000 can be manually stepped
through all or some of the stored set-
points. The procedure is as follows:
a. Press “Shift” followed by “Man”.
b. Using the arrow keys, toggle up and

down through the stored setpoints.

c. To exit press CE or simply enter a new

output value.

5. Pressure Module Interface

The MC1000 has the capability to inter-
face with a family of pressure modules
available from Martel. The procedure is
as follows:

a. Connect the pressure module to the

15 pin “D” connector on top of the
MC1000.

b. Press “Shift” followed by the “ ”

key.

c. Always zero the pressure module

before starting a calibration. Press
“Shift” followed by the “Zero” key.

Note: More detailed information can be found with
the instructions packaged with each module.
