４．Instrument Layout
Transformer Jaw
Jaw Trigger
Display
Mode Switch
Reset Switch
Data Hold Switch
Terminal Cover
Drop Prevention Strap
Ｖ／Ω Terminal
COM Terminal
OUTPUT Terminal
︸
Test Leads
Ｍー7107
Recorder Output Plug
Ｍー8102
Data Hold Mode
Resistance
Voltage
Current
Peak Mode Measurement
Battery Voltage Alert
Continuity Check Mode
Negative Potential
AC Current
DC Current
● ＬＣＤ INDICATOR
Function Switch
