Electrical connections – KROHNE LS 6500 EN User Manual
Page 19
ELECTRICAL CONNECTIONS
4
19
LS 6500
www.krohne.com
03/2013 - 4000649103 - MA LS 6500 R03 en
DANGER!
Disconnect the power supply before connecting the configuration tool to the switch!
Figure 4-1: Electrical connection of configuration tool
a = red alligator clip
b = black alligator clip
INFORMATION!
Ambient temperature range is 0...+50°C / +32...+122°F.
DANGER!
The configuration tool cannot be connected to the LS 6500 within the hazardous area. For
programming, remove the device out of this area.
.book Page 19 Tuesday, March 12, 2013 11:33 AM
