OPERATION
5
27
OPTIBAR P 3050 C
www.krohne.com 03/2012 - 4001953401 - MA OPTIBAR P3050C R02 en
5.5.2 Structure of the operating menu
Measuring mode/menu Function of the existing buttons
Display mode and normal mode MENU: indicate menu
BACK: back to indication
• ↓: contrast darker
• ↑: contrast lighter
Selection mode and configuration
menu
SEL: select menus
BACK: one level back
↓: navigate down the list
↑: navigate up the list
Editing menu Edit numerical value: Edit numerical value: Edit numerical value: Edit numerical value:
SEL: select digit position
BACK: store
↓: reduce value or browse character map
↑: increase value or browse character map
Confirm set numerical value:
Confirm set numerical value: Confirm set numerical value: Confirm set numerical value:
EDIT: back to editing mode
BACK: one level back
QUIT: reset to original value
SAVE: save new value
Selection from list or confirm action: Selection from list or confirm action: Selection from list or confirm action: Selection from list or confirm action:
SAVE: save selection
BACK: one level back
↓: navigate down the list
↑: navigate up the list
