5
MODBUS PROTOCOL
26
MFC 400
www.krohne.com 05/2013 - 4002525102 - AD Modbus MFC 400 R02 en
5.8.15 Concentration 1
INFORMATION!
Only available with option "concentration measurement".
Modbus Function Codes "Read Holding Registers" (0x03) and "Write Multiple Registers" (0x10)
Holding
Register Name Type No. of
registers Values Display
Fct. No.
42000 42000 42000 42000
(0xA410)
Function Byte 1 0 = Off
2 = Brix
3 = % Mass
4 = Baume 144
5 = Baume 145
6 = % NaOH
7 = Plate
8 = % Volume
9 = API
10 = % Alcohol by mass
11 = % Alcohol by volume
C2.2.1
42001 42001 42001 42001
(0xA411)
Product Byte 1 0 = % of Product A
1 = % of Product B
C2.2.3
42002 42002 42002 42002
(0xA412)
CCF01 Byte 1 0 = linear
1 = non linear
C2.4.1
42003 42003 42003 42003
(0xA413)
CCF05 Byte 1 0 = pure water
1 = town water
2 = other
C2.4.5
42050 42050 42050 42050
(0xA442)
Offset Float 2 -100...100 [%] C2.2.2
42052 42052 42052 42052
(0xA444)
CCF02 Float 2 - C2.4.2
42054 42054 42054 42054
(0xA446)
CCF03 Float 2 - C2.4.3
42056 42056 42056 42056
(0xA448)
CCF04 Float 2 - C2.4.4
42058 42058 42058 42058
(0xA44A)
CCF06 Float 2 - C2.4.6
42060 42060 42060 42060
(0xA44C)
CCF07 Float 2 - C2.4.7
42062 42062 42062 42062
(0xA44E)
CCF08 Float 2 - C2.4.8
42064 42064 42064 42064
(0xA450)
CCF09 Float 2 - C2.4.9
42066 42066 42066 42066
(0xA452)
CCF10 Float 2 - C2.4.10
42068 42068 42068 42068
(0xA454)
CCF11 Float 2 - C2.4.11
42070 42070 42070 42070
(0xA456)
CCF12 Float 2 - C2.4.12
