MODBUS PROTOCOL
5
17
MFC 400
www.krohne.com 05/2013 - 4002525102 - AD Modbus MFC 400 R02 en
5.8.5 Auxiliary Values
5.8.6 Totaliser
Modbus Function Codes "Read Input Registers" (0x04)
Input
Register Name Type No. of
registers Units Display
Fct. No.
31000 31000 31000 31000
(0x7918)
Drive Level Float 2 [%] B2.11
31002 31002 31002 31002
(0x791A)
Sensor A Level Float 2 [%] B2.12
31004 31004 31004 31004
(0x791C)
Sensor B Level Float 2 [%] B2.13
31006 31006 31006 31006
(0x791E)
Strain 1 Float 2 [Ω] B2.8
31008 31008 31008 31008
(0x7920)
Strain 2 Float 2 [Ω] B2.9
31010 31010 31010 31010
(0x7922)
Tube Frequency Float 2 [Hz] B2.10
31012 31012 31012 31012
(0x7924)
2 Phase Signal Float 2 - B2.14
31014 31014 31014 31014
(0x7926)
SE PCB Temperature Float 2 [K] B2.15
Modbus Function Codes "Read Coils" (0x01) and "Write Single Coil" (0x05)
Coil
Address Name Function Action Values Display
Fct. No.
3000 3000 3000 3000
(0x0BB8)
Totaliser 1 Start / Stop Write 0 = stop totaliser
1 = start totaliser
C4.1.8 /
C4.1.9
Status Read 0 = totaliser stopped
1 = totaliser running
-
3001 3001 3001 3001
(0x0BB9)
Totaliser 2 Start / Stop Write 0 = stop totaliser
1 = start totaliser
C4.2.8 /
C4.2.9
Status Read 0 = totaliser stopped
1 = totaliser running
-
3002 3002 3002 3002
(0x0BBA)
Totaliser 3 1 Start / Stop Write 0 = stop totaliser
1 = start totaliser
C4.3.8 /
C4.3.9
Status Read 0 = totaliser stopped
1 = totaliser running
-
3003 3003 3003 3003
(0x0BBB)
Totaliser 1 Reset set totaliser value
to zero
Write 1 = reset totaliser C4.1.6
3004 3004 3004 3004
(0x0BBC)
Totaliser 2 Reset set totaliser value
to zero
Write 1 = reset totaliser C4.2.6
3005 3005 3005 3005
(0x0BBD)
Totaliser 3 Reset
1
set totaliser value
to zero
Write 1 = reset totaliser C4.3.6
1 Only available in signal converters with "modular carrier"
