7
3.3 Output of Concentration Values
Tables 3.3.1,3.3.2 and 3.3.3 show the additional output functions that are available with the
different concentration options. These may be programmed in the normal way as described in
the Standard Operating manual.
Table 3.3.1 Current Output Function Variations for Concentration systems
Concentration Option
NONE BRIX BAUMÉ GEN. CONC. NaOH
OFF OFF OFF OFF OFF
MASS FLOW MASS FLOW MASS FLOW MASS FLOW MASS FLOW
DENSITY DENSITY DENSITY DENSITY DENSITY
TEMPERATUR. TEMPERATUR. TEMPERATUR. TEMPERATUR. TEMPERATUR.
VOL. FLOW VOL. FLOW VOL. FLOW VOL. FLOW VOL. FLOW
DIRECTION BRIX RATE SOLUTE. FLOW SOLUTE. FLOW SOLUTE. FLOW
BRIX BAUME CONC.BY.MASS CONC.BY.MASS
DIRECTION DIRECTION CONC.BY VOL DIRECTION
DIRECTION
Table 3.3.2 Pulse Output Function Variations for Concentration systems
Concentration Option
NONE BRIX BAUMÉ GEN. CONC. NaOH
OFF OFF OFF OFF OFF
MASS FLOW MASS FLOW MASS FLOW MASS FLOW MASS FLOW
MASS TOTAL MASS TOTAL MASS TOTAL MASS TOTAL MASS TOTAL
DENSITY DENSITY DENSITY DENSITY DENSITY
TEMPERATUR. TEMPERATUR. TEMPERATUR. TEMPERATUR. TEMPERATUR.
VOL. FLOW VOL. FLOW VOL. FLOW VOL. FLOW VOL. FLOW
VOL. TOTAL VOL. TOTAL VOL. TOTAL VOL. TOTAL VOL. TOTAL
DIRECTION BRIX RATE SOLUTE. FLOW SOLUTE. FLOW SOLUTE. FLOW
SUC. TOTAL SOL. TOTAL SOL. TOTAL SOL. TOTAL
BRIX BAUME CONC.BY.MASS CONC.BY.MASS
DIRECTION DIRECTION CONC.BY VOL DIRECTION
DIRECTION
Table 3.3.3 Alarm Output Function Variations for Concentration systems
Concentration Option
NONE BRIX BAUMÉ GEN. CONC. NaOH
OFF OFF OFF OFF OFF
MASS FLOW MASS FLOW MASS FLOW MASS FLOW MASS FLOW
MASS TOTAL MASS TOTAL MASS TOTAL MASS TOTAL MASS TOTAL
DENSITY DENSITY DENSITY DENSITY DENSITY
TEMPERATUR. TEMPERATUR. TEMPERATUR. TEMPERATUR. TEMPERATUR.
VOL. FLOW VOL. FLOW VOL. FLOW VOL. FLOW VOL. FLOW
VOL. TOTAL VOL. TOTAL VOL. TOTAL VOL. TOTAL VOL. TOTAL
DIRECTION BRIX RATE SOLUTE. FLOW SOLUTE. FLOW SOLUTE. FLOW
SEVERE ERR. BRIX BAUME CONC.BY.MASS CONC.BY.MASS
ALL MSG. DIRECTION DIRECTION CONC.BY VOL DIRECTION
I1 SAT SEVERE ERR. SEVERE ERR. DIRECTION SEVERE ERR.
P1 SAT ALL MSG. ALL MSG. SEVERE ERR. ALL MSG.
ANY OP. SAT. I1 SAT I1 SAT ALL MSG. I1 SAT
P1 SAT P1 SAT I1 SAT P1 SAT
ANY OP. SAT. ANY OP. SAT. P1 SAT ANY OP. SAT.
ANY OP. SAT.
